Technische Daten
Imaging modes | B Mode B+B Mode B+M Mode |
Frequency | range: 2-14 MHz (depends on probe) |
Probes | Backfat 2-5 MHz Convex 2-5 MHz Convex 2-8 MHz Abdominal linear 6-14 MHz Microconvex 4-9 MHz OPU 4-9 MHz Rectal linear 4-9 MHz Rectal convex 2-8 MHz Rectal microconvex (P-probe) 4-9 MHz |
Dynamic Focus | Yes |
Image management | Freeze Zoom 60 – 200% Full screen Invert left-right Image rotation Saving images Saving cine loops |
Imaging adjustment | Frame averaging Negative LuciD |
Presets | Possible to save 5 presets |
Postprocessing | Yes (LuciD) |
Measurements | Distance, Follicle, Area, Area polygon, Volume, Grid, Backfat Obstetric package: aging tables for different species Needle |
Workflow tools | Personalised Quick Access Menu |
Display | 7″ LCD LED 500 cd/m2 800 x 480 px |
Control panel | Membrane keyboard |
Memory | 200 images 200 cine loops |
Exported file format | AVI, BMP |
Exporting data method | To external flash drive via USB connector To mobile App by WiFi (images only) |
Multimedia ports | 6-pin connector for data transfer 12-pin connector for goggles |
WiFi connection to mobile devices | No |
Power supply | Battery |
Battery operating time | Up to 7 h |
Battery charging time | Up to 4 h |
Booting time | < 20 s |
Dimensions | Width 25.6 cm, Height 16.5 cm, Depth 6.9 cm |
Weight (with probe and battery) | 2.64 kg |
Ingress Protection (IP) rating | IP32 |
Zubehör
- Stand
- OLED goggles
- OPU
- Extension and T-holder for rectal linear or rectal convex probe
- Shade cover
- Bag with shade cover
- Transport bag
- Suspenders
- Waist belt
- Standoff
- Wi-Fi Antenna
